LAPETEK JONA Slim-V 90
90 cm, island black In stock
JONA SLIM-V
The popular LAPETEK JONA SLIM-V island model has been redesigned both technically and visually. The slim, even more trendy design guarantees a timeless look with both a modern and more traditional kitchen look. The finished streamlined look is accentuated by the uniform narrower design of the front panel and flue. Available in...
Accessories and Cleaners
Product Details
JONA SLIM-V
The popular LAPETEK JONA SLIM-V island model has been redesigned both technically and visually. The slim, even more trendy design guarantees a timeless look with both a modern and more traditional kitchen look. The finished streamlined look is accentuated by the uniform narrower design of the front panel and flue. Available in white, stainless steel and black.
The suction power has been increased, but still the energy class has been improved and the sound level is pleasantly quiet, especially at normal power. The power of the cooker hood lights has also been increased and they are placed on both the front and rear edges of the cooker hood. The suction area is in the middle of the cooker hood, so that the steams are most efficiently directed into the cooker hood.
An easy-to-use backlit Soft Touch keyboard, powerful LED lights and easy-to-clean grease and active carbon filters make using the cooker hoodfan easy and pleasant. You can choose an ecological and washable Long Life filter as the active carbon filter.
JONA SLIM models are available in both 60 cm and 90 cm wide wall-mounted models and 90 cm wide island models. All models and color options are available with their own motor, in addition to which wall models are available with external motor control (for X1-AC and EC motors), humid room enhancement (for X2-AC and EC motors) and valve control for apartment buildings (X3).
The easy-to-use backlit Soft Touch operating buttons, powerful and pleasantly smooth LED lights and easy-to-clean grease filters make using the cooker hood easy and pleasant.
Operating functions
The stylishly backlit, front-panel-integrated Soft Touch operating buttons are easy to use and has a pleasant feel. The adjustable timer function ensures that the steams leave the room even after cooking has stopped.
Powerful LED lights illuminate pleasantly and evenly the entire surface below. In addition, the luminaires come standard with a three-stage dimming function and color temperature control, which allows you to adjust the lighting to suit the mood and other lighting around the cooker hood.
You can choose a disposable replaceable filter or a more environmentally friendly washable and reactivable Long Life filter as the active carbon filter. In both cases, the filter is very easy to install because it attaches directly to the grease filter and not to the sides of the engine inside the hood in the traditional way.
Installation
The easiness of installation has been taken into account when designing the attachmenting the new model. There is enough space inside the frame for lateral displacements of the pipeing. With the cooker hood a control part has also been added to improve the control when used with the active carbon filters, in air operation, which allows the air to be directed back to the room air.
The new Jona Slim-V is also all-inclusive. The pipe has been extended from the previous one, so that the room height can be 280 cm without the need for an additional flue. For rooms with high ceilings, an extension part is available that allows the LAPETEK JONA SLIM-V-X-model to be installed up to a room height of 329 centimeters. In all maximum room heights, by default, the stove top is 900 mm from the floor and the bottom edge of the kitchen hood is 650 mm from the stove top, i.e. the bottom edge of the kitchen hood is at a height of 1550 mm as seen from the floor. If the kitchen hood is installed at a different height, it also affects the minimum and maximum room heights.
Installing the cooker hood is easy and quick to do with clear instructions and installation pictures.
Package contains
- cooker hood black
Dimensions and technical data
In scope of supply | - cooker hood black |
Ventilation system | Own motor |
Cooker hood color | Black |
Suitable for the room height | 249 - 282 cm |
Cooker hood width | 90cm |
With the air chimney extension | max. 329 cm |
With active coal | 249 - 282 cm |
Max. suction power | 410 m3/h (intensiivi 680 m3/h) |
Max. Volume level | 59 dB(A) (intensiivi 68 dB(A)) |
Electrical connection | Socket 10 A |
Lightning | LED 4 x 3 W / (2700 - 5500 K) 3-portainen himmennys, värilämpötilan säätö |
Blast connection diameter | 150 mm |
Weight kg (without packaging) | 25.26 |
Switch functions | Taustavalaistu Soft touch -näppäimistö - valot päälle / pois - perusnopeudet 1-3 (numeronäyttö kertoo valitun nopeuden) - intensiivitoiminto (5 min) - ajastettu sulkeminen (10 - 90 min) |
Minimum installation height | 65 cm for gas stoves |
Minimum installation height | 55 cm for electric stoves |
Fat filter | Washable metal |
Back-pressure valve | Included in delivery |
Energy class | B |
Warranty months | 24 |
